Technical specifications can be customized based on airflow requirements, installation conditions, and filtration targets. Contact us for detailed ...
View full detailsFiltration Grade Dimensions (mm) W*H* D Filter Area (㎡) Rated Air Flow (m³/h) Wind Velocity Test (m/s) Initial Resistance (Pa) H13 610*610*120...
View full detailsDimensions (mm) W*H* D 595*595*550 / 6P Filtration Grade G4 M5 M6 F7 F8 F9 Air Flow (m³/h) 3400 3400 3400 3400 3400 3400 Initial Resistanc...
View full detailsStandard sizes and multiple bag configurations are available for different airflow requirements and filtration targets. Custom specifications can a...
View full detailsF6 or M6 filter specifications may still appear in existing HVAC equipment documentation and replacement filter requirements. When selecting new filters, buyers should confirm the applicable ISO 16890 performance data, airflow requirements, dimensions, and pressure drop.
Clean-Link offers different air filter configurations for HVAC replacement and project-specific filtration requirements.
F6-class filtration has historically been specified in ventilation systems where medium-efficiency particle removal is required.
Common applications include:
Commercial office buildings
Hotels and retail environments
Public buildings and general ventilation systems
Industrial air handling units (AHUs)
HVAC systems requiring intermediate or final-stage filtration
The appropriate filtration stage depends on the air cleanliness requirements, system design, and downstream filtration equipment.
Filters associated with historical F6 or M6 specifications may be available in different constructions, depending on the manufacturer and tested configuration.
Pocket filters provide a relatively large filtration media area and are commonly used in commercial and industrial air handling units. Available configurations may include synthetic or fiberglass media, multiple pocket counts, and different installation depths.
Explore our Pocket & Bag Filters for suitable HVAC filtration options.
Panel and pleated filter designs may be suitable where installation space, frame dimensions, or replacement requirements favor a more compact construction.
View our Panel & Pleated Filters for available configurations.
Filter efficiency classification should always be confirmed against the specific product's technical documentation.
When selecting an F6 or M6 replacement filter, important factors include:
Filtration efficiency: Confirm the applicable classification and supporting test data.
Airflow rate: Match the filter to the required operating airflow.
Pressure drop: Consider both initial resistance and the recommended replacement pressure drop.
Filter dimensions: Verify the frame size, depth, and installation requirements.
Dust-holding capacity: Evaluate expected dust loading and maintenance intervals.
Actual performance and energy consumption depend on the filter construction and operating conditions.
Replacement filters should be selected based on the original equipment specifications and the requirements of the ventilation system.
Clean-Link supports discussions involving standard and custom air filter dimensions, filter media, frame configurations, and bulk purchasing requirements.
For non-standard sizes or OEM projects, learn more about our Custom Air Filter Manufacturing capabilities.
When requesting a quotation, please provide the filter dimensions, required efficiency classification, airflow rate, estimated quantity, and any available drawings or existing filter specifications.
F6 is a historical EN 779:2002 filtration class used for medium-efficiency general ventilation filters. It was redesignated M6 under EN 779:2012.
Under EN 779:2002, F6 filters had a higher specified average efficiency range for 0.4 μm particles than F5 filters. In EN 779:2012, these classes were redesignated M6 and M5.
There is no universal one-to-one conversion between F6 and ISO 16890 classifications. The ISO ePM rating should be determined from the specific filter's test results.
Depending on the ventilation system and required air cleanliness, an F6 or M6-class filter may serve as an intermediate or final filtration stage. Applications with more demanding particulate control requirements may need higher-efficiency filters.
Energy consumption depends partly on filter pressure drop, system airflow, fan operation, and maintenance conditions. Filter efficiency classification alone does not determine energy performance.
